Although it is useful, the truth is electricity can also be dangerous. Electricity can cause fires if there is a short circuit or cause electric shocks when there is a leak.
Every year, around 400 people experience electric shocks at home, and 200 of them can die. This is because an electric current of 80 mA if it flows through humans can cause heart problems.
Therefore, Law No. 30 Article 29 of 2009 stipulates that consumers are required to implement security against the dangers of using electricity. One way is to use a circuit breaker such as an MCB (Miniature Circuit Breaker). However, the General Requirements for Electrical Installations instruct the use of additional equipment other than MCBs, such as ELCBs (Earth Leakage Circuit Breakers), to prevent fault currents from flowing through humans, livestock, and also things that cause fires.
Instead of having to install two protection devices, there is another alternative that is easier and more concise, namely using an RCBO that has a combination of MCB and ELCB functions.
You can find the complete specifications of the RCBO DOMD01606 in this article!
What Is RCBO Slim Domae DOMD01606 Schneider Electric?
RCBO (Residual Current Circuit Breaker with Overcurrent Protection) is an electrical device that can cut off the current to protect the electrical system from leakage currents or excess currents.
The RCBO Slim Domae itself is a residual current breaker and overcurrent protection produced by Schneider Electric. What distinguishes the RCBO Slim from the RCBO in general is the width of the product. The RCBO Slim has the same width as the MCB Domae 1 Pole, which is around 18mm. With its slimmer size, it can save more space in the MCB Box.
Residual current circuit breakers are usually used in residential and commercial electrical installations, especially in places that are at high risk of electric shock, namely humid places such as bathrooms or kitchens.
What Are the Specifications and Advantages of the RCBO Slim Domae DOMD01606 Schneider Electric?
RCBO DOMD01606 is one type of RCBO Slim Domae Schneider Electric with a rated current of 6 Ampere and has many advantages. You can check the spesifications and advantages here:
Specifications:
- Rated Current: 6A
- Curve Code: C
- Earth Leakage Protection Class: AC Type
- Sensitivity: 30mA
- Frequency: 50 Hz
- Product color: White (RAL9003)
- Product size: (W) 18mm x (H) 93mm x (D) 70mm
- Weight: 136 grams
- The Icn rated short circuit breaking capacity is up to 6000A.
- Can be mounted on DIN rail
- Compliant with EN 61009-1 standard
- According to the IEC 60529 standard, the protection level is IP20 and IP40 on the enclosure
Advantages:
- 3 Protections in 1 Product: Overload, Short Circuit, and Leakage Current (Electrocution)
- Slimmer dimensions with a width of only 18mm, the same as the width of 1 MCB
- Easy installation, simply remove the MCB, then replace it with RCBO Slim Domae DOMD01606 Schneider Electric, and install the neutral cable
- SNI Certified
To download the RCBO Slim Domae DOMD01606 Schneider Electric datasheet, you can click here!
