Electric Vehicle (EV) has become a new breakthrough in creating environmentally friendly transportation. In a short time, electric vehicles have become a favorite, including in Indonesia.
With the increasing number of electric vehicle (EV) users, charging facilities must also be improved. Charging facilities can be supported by the presence of an EV Charger. The best choice of quality EV Charger that has many advantages is the EV Charger from Himel!
Having many choices of EV Charger types that can be chosen according to your needs, this article will discuss the EV AC Charger type HHEV2107HP! What are the functions and complete specifications? Check out the following explanation, let's go!
Understanding the EV AC Charger HHEV2107HP Himel
The EV AC Charger HHEV2107HP Himel is a charging device for electric vehicles or electric vehicles, that uses alternating current (AC) to charge its battery. This AC charger for EVs is generally used in homes and also buildings with low electrical power.
This EV AC Charger is one type of EV Charger. In general, there are three types of EV Chargers, namely Level 1 (Slow Charging), Level 2 (Fast Charging), and Level 3 (Fast Charging). Level 1 and Level 2 are AC-type chargers, while Level 3 is a DC charger. In principle, the greater the EV charging power, the less time it takes to charge.
The way this tool works is by converting AC current from the charging station to DC current on the EV's internal charger. AC charging is considered a "low and slow" charge.
Understanding the Function of the EV AC Charger HHEV2107HP Himel
Basically, the EV AC Charger HHEV2107HP Himel has more or less the same function as a device charger in general, namely to charge the battery. In this case, it is to charge the battery of an electric vehicle so that the vehicle can operate optimally and have more environmentally friendly mobility.
Getting to Know the EV AC Charger HHEV2107HP Himel Specifications
As one of the EV Chargers from HIMEL, the HHEV2107HP product has specifications that are not much different along with its own advantages. Generally, the Himel EV Charger has a simple and neat design, besides that, it is also easy to install and easy to use.
For the complete EV AC Charger HHEV2107HP specifications, you can see below!
Specifications:
- Input Wiring Scheme: 1P+N+PE and 3P+N+PE
- Rated Voltage: 230 VAC for 1P+N+PE and 400 VAC for 3P+N+PE
- Network Frequency: 50/60 Hz
- Maximum Current: 16A or 32A
- Rated Power: 7.4 kW for 1P+N+PE and 11kW or 22kW for 1P+N+PE
- Charger Connector: Type 2 Plug
- Cable Length: 5m
- LED Indicator: Green/Blue/Red
- LCD Display: 4.3” Color Touch Screen
- Ingress Protection: IP55
- Impact Protection: IK10
- Equipped with RCD (Residual Current Device) Type A+DC 6mA
- The cooling method used is Natural Cooling
- There is protection for over or under voltage, protection overcurrent, short circuit protection, over or under temperature protection, lightning protection, up to ground protection
That's the explanation of the EV AC Charger HHEV2107HP Himel, complete with its specifications. With its superior features, this EV Charger from Himel can be the right choice for more efficient electric vehicle charging!
