CLIMASYS CC DOUBLE THERMOSTAT 250V RANGE OF TEMPERATURE 0 60C 1NO/NC C

Spesifikasi NSYCCOTHD ClimaSys CC - double thermostat 250V - range of temperature 0…60°C - 1NO/NC - °C

Untuk unduh datasheet produk, silakan klik disini!
Untuk unduh Catalog, silakang klik disini!
Untuk unduh Instruction Sheet, silakang klik disini!

Main :
range : ClimaSys
product name : ClimaSys CC
product or component type : Double thermostat
temperature setting range : 0…60 °C
information displayed : Temperature in °C

Complementary :
input voltage : 250 V
sensor type : Bimetal
contacts type and composition : 1 NO/NC
contact resistance : 10 mOhm
service life in cycles : 100000 cycles
maximum switching capacity : 2 A 120...250 V AC inductive pf: 0.6
 : 10 A 250 V AC resistive
 : 15 A 120 V AC resistive
 : 30 W DC
electrical connection : 4 terminals, clamping capacity: 2.5 mm²
mounting mode : Clipped
height : 68 mm external:
width : 56 mm external:
depth : 44 mm external:
net weight : 40 g
mounting location : Spacial upright
 : On mounting plate
 : 35 mm DIN rail
 : Cross rails
ambient air temperature for operation : -20…80 °C
IP degree of protection : IP20
hysteresis : 7 %
number of outputs : 1 heating function
 : 1 ventilation function
material : PC
colour : Light grey
flame retardance : Self-extinguishing conforming to UL94 (material V0)
product certifications : UL

Packing Units :
Unit Type of Package 1 : PCE
Number of Units in Package 1 : 1
Package 1 Weight : 105.57 g
Package 1 Height : 6 cm
Package 1 width : 7 cm
Package 1 Length : 8 cm
Offer Sustainability :
REACh Regulation : REACh Declaration
REACh free of SVHC : Yes
EU RoHS Directive : Compliant
 : EU RoHS Declaration
Mercury free : Yes
RoHS exemption information : Yes
China RoHS Regulation : China RoHS declaration
 : Product out of China RoHS scope. Substance declaration for your information

Contractual warranty :
Warranty : 12 months


ClimaSys CC Double thermostat. 250V AC. 68 x 56 x 44 mm. Sensor Bimetal with 1 NO/NC contact type. 1 heating function and 1 ventilation function. Electrical connection by 4 terminals 2.5mm². Mounting mode by 35mm DIN rail, cross rails, on mounting plate Spacial upright. Made in PC. Light grey. Self-extinguishing UL94 (material V0). Protection IP20.

Specification

With digital indication	FALSE
Rated voltage AC 50 Hz	200…240 Volt
Rated voltage AC 60 Hz	200…240 Volt
Temperature setting range	0…60 Degrees celsius
Model	Thermostat
Rated current In	10 Ampere
Mounting method	Other
Type of switch function	Normally closed contact and normally open contact
