SWITCH DISCONNECTORS 4P 1000A
SWITCH DISCONNECTORS 4P 1000A

SWITCH DISCONNECTORS 4P 1000A

Pilih Jumlah kutub
Pilih Arus pengenal
Kode Produk 31333
Nama Produk SWITCH DISCONNECTORS 4P 1000A
Keterangan SWITCH DISCONNECTOR COMPACT INS1000 SCHNEIDER ELECTRIC - 31333
Brand Schneider Electric
Poles 4P
Rated Current 1000A
Tipe Compact INS
Ketersediaan Stok
Kode Produk : 31333 Brand : Schneider Electric Nama Produk : SWITCH DISCONNECTORS 4P 1000A Keterangan : SWITCH DISCONNECTOR COMPACT INS1000 SCHNEIDER ELECTRIC - 31333

This Compact INS1000 is a 4 poles non-automatic switch-disconnector with black rotary handle. It is suitable for isolation with positive contact indication, as defined by IEC 60947-1 and IEC60947-3 standards. The operational current is 1000A at 415VAC in categories AC21A, AC22A and AC23A. The rated voltage is 690VAC 50/60Hz or 250VDC. The black rotary handle is designed to offer easy operation and high performance in interruption of currents. Compact INS1000 is a class II insulation level front-face device as per IEC 60664 standard.

Specification
Type of electrical connection of main circuit Screw connection
Version as emergency stop installation FALSE
Type of control element Long turning handle
Version as reversing switch FALSE
Suitable for front mounting centre TRUE
Rated permanent current Iu 1000 Ampere
Max. rated operation voltage Ue AC 690 Volt
Number of poles 4
Height 300 Millimetre
Version as main switch TRUE
Rated short-time withstand current lcw 50 kiloampere
Voltage release optional FALSE
Device construction Built-in device fixed built-in technique
Interlockable TRUE
Width 410 Millimetre
Version as maintenance-/service switch TRUE
Version as safety switch FALSE
Number of auxiliary contacts as normally closed contact 0
Number of auxiliary contacts as change-over contact 4
Number of auxiliary contacts as normally open contact 0
Degree of protection (IP), front side IP40
Depth 146.5 Millimetre
Rated operating voltage 690 Volt
Colour control element Black
Suitable for front mounting 4-hole TRUE
Rated operation power at AC-23, 400 V 560 Kilowatt
Number of switches 1
Motor drive integrated FALSE
Rated permanent current at AC-21, 400 V 1000 Ampere
Suitable for distribution board installation TRUE
Suitable for intermediate mounting FALSE
Motor drive optional FALSE
Suitable for floor mounting TRUE
With pre-assembled cabling FALSE
Rated permanent current at AC-23, 400 V 1000 Ampere
Documents
Image of product
Image of product

Chat untuk Stock

Rp.28.238.678,-

45% Rp.51.343.050,-

Add to Cart
